Wireless Backhaul Solutions

Mobile operators also need to maximize utilization of each bit of transport in that backhaul network and must manage this bandwidth efficiently to create a satisfying quality for subscribers, using of differentiated multimedia Services  varying QoS requirements. EC SYSTEM´s wireless Backhaul solutions are completely standards based and fully interoperable. EC-LINK, optimised for Small Cell NLOS wireless Backhaul,Carrier Backhaul, Long-range Backhaul and LTE-Backhaul is very usefull also in urban areas where high radio interference is an issue coupled with Non- Line-of-Sight (NLOS) problems. EC SYSTEM wireless backhaul solution is capable of delivering IP traffic of up to 480 Mbps. Such solutions are deployed by tier-1 carrier providers worldwide for backhaul 2G-4G  radio access networks (RAN) in cities and remote areas. EC SYSTEM point-to-point is a cost-effective alternative solution to leased lines and microwave links that cannot operate in nLOS conditions and areas over-water. EC SYSTEM broadband backhaul system  performs well in extreme environments where there are harsh weather conditions. This applies to 3GHz licensed and 5 GHz-6 GHz unlicensed bands in non-line-of-sight conditions.

Applications:

• Host of Cellular Backhaul applications
• Rapid and cost effective cellular network expansion to remote locations
• Roll out of 3G/4G overlay in cities
• Rapid cost-effective network extension
• Long-haul IP connectivity
• Wi-Fi access point & 3G Small Cell Backhaul
• Backhauling access networks (e.g. small DSLAM, wireless PtMP)
• Lightweight high spectral efficiency backhaul for WISP or mobile operator networks
• High-capacity wireless Backhaul for IP-based CCTV networks
• NLOS wireless Backhaul

Benefits:

• Capacity throughput of up-to 500 Mbps
• Up to 16 E1 + Ethernet in a single radio
• Long range performance of up to 80 KM
• LOS (line-of-sight) and NLOS (non-line-of-sight) deployment
• Network expansions fast and easy
• Plug & play solution with operating frequencies of 5-6GHz for Ultra-long wireless Backhaul links
• Advanced Quality-of-Service features
• Provides comprehensive plan for Small Cell Backhaul deployment
• TDD synchronization through IEEE1588, bulit-in GPS receiver
• Multiple bands supported by a single radio
• Multiple channel widths between 3.5-40 MHz
• The best spectral efficiency
• Superior performance and processing power
• Multiple management and monitoring options
• Availability 99.999% along distances up to 20-30 km

Reliability and robustness of outdoor design

• IP66/IP67
• Operating temperature -40+60C
• Built-in surge protection

Extended QoS functionality

• Recognition of RTP traffic – automatic voice detection and prioritization
• Aware of the QoS  standarts 802.1p/ToS/DiffServ –traffic selection and prioritization
• Filtering criteria based on IP or MAC addresses,TCP/UDP ports,VLAN tags etc
• Up to 17 priority queues
• Traffic shaping
• Dynamic bandwidth allocation for different Services

Advanced networking support for Backhaul

• Tunneling (IP-over-IP,Ethernet-over-IP)
• MAC/IP filtering
• Full featured L2 switch (Full VLAN support, STP,Multicast(IGMP snooping),Q-in-Q link aggregation
• IP routing  (Static, RIPv1/v2,OSPFv2)
• Multipool NAT
• L2/L3 IP-Firewall
• DHCP client/server/relay

Security of data transmission

EC SYSTEM wireless equipment has strong security fetures to ensure data transfer in the most secure way.

Unit protection:

• Password protected CLI and Web interface
• SNMPv3,
• SSH and HTTPS options for unit management
• Management VLAN

Data integrity:

• Advanced over the air encryption
• Network Security:
• Built-in storm and flood protection
• Built-in full-fledged IP Firewall to filter traffic
• Tunneling
• VLANs

Point-to-Point Wireless Backhaul solution
